Lcn 71 Door Closer Adjustment

Lcn closers ingersoll rand company p o.

Lcn 71 door closer adjustment. Box 100 121 w. We ve simplified product installation with digital step by step instructions for the lcn 4040xp product just scan the qr code printed on the paper instructions in the box. 4 grade 1 durability strength and performance standards for door controls. Lcn installation instructions templates index 1250 series mounting document template number pull top jamb pa mounts 71375 eda and heda 71378 cush and spring cush mounts 71379 drop plate 71930 419 flush adapter 72012 1260 series.

Princeton il usa 61356 0100 closer mounts hinge pull side top jamb push side parallel arm push side hinge pull side mount shown. The 4000 series surface mounted is the most comprehensive and versatile line offered by lcn. For frequently used doors these closers last twice as long as standard door closers. The 1260 series is cul listed and ul listed for self closing doors without hold open and boasts a 20 year limited warranty.

Features also include optional slim line cover lcn peel n stick templates for quick and accurate installation convenient spring adjust pointer and an optional quick fix bracket kit. The big body 4010 4020 4040 and 4110 all feature the fast power adjust indicator for spring power adjustment. All lcn and falcon door closers will have 3 regulating valves and a spring adjustment all closers with a delay feature will have an additional 4th valve. Closers automatic operators created date.

4th 2008 the 1260 closer hole pattern is 9 1 16 x 3 4 which is not the same hole pattern as the 1370 closer. We no longer carry any 1370 series parts but our current 1260 and 1460 arm will fit on the 1370. The 1260 18qf plate does have the same hole pattern as the 1370 closer. Closers that meet ul 10c for fire rated doors meet positive pressure fire test standards.

For specific instructions on your closer see installation instructions here. The 1370 series closer was discontinued on oct. Make adjustments below as required. Lcn heavy duty security door closers feature cast iron cylinders forged steel arms all weather fluid and double heat treated pinions that help provide long service life.

They can replace yale dorma falcon stanley parker and cal royal models with the same mounting hole pattern. They do not include covers.
